Rack Protection Sensor

The Innovative Rack Protection System
Rack Protection Sensor from Linde Material Handling

The majority of rack damage in warehouses is caused by industrial trucks. The drivers need to focus fully on the pallet, especially when storing and retrieving goods in the higher rack levels. This makes it difficult for them to stay aware of the distance to the rack at the same time. This often results in collisions and damage, affecting the rack system as a whole structure and generating high repair costs. Expensive skirting and support protection devices are often fitted to rack columns aimed at minimizing these risks. However, over time these also tend to get damaged by collisions and also provide no protection for the goods stored at ground level.

Fitting trucks with the Linde Rack Protection Sensor is a much more efficient solution. The innovative rack protection system acts as the driver’s eyes at ground level and automatically slows down the reach truck before it collides with the rack. The assistance system can therefore prevent accidents involving the rack columns and goods stored at ground level, thereby improving safety in the warehouse and saving on repair costs. At the same time, the Rack Protection Sensor makes the driver’s job easier, enabling them to concentrate fully on storing and retrieving goods with precision and helping to increase handling capacity in the process.

Manfred Martens, Finished Products Warehouse Operations Manager at Sopro Bauchemie GmbH
Linde came to me and asked if we would be able to test something like this: a rack protection system which is mounted on the truck to prevent the driver from colliding with the rack frame and damaging it with the support arm. We trialed it and found it worked very well.

Manfred Martens, Finished Products Warehouse Operations Manager—Sopro Bauchemie GmbH, Wiesbaden

Prevent Rack Damage with the Rack Protection Sensor from Linde

The Features of the Rack Protection Sensors at a glance

The intelligent braking assistant of the Rack Protection Sensor from Linde Material Handling

Intelligent Braking Assistant

The Rack Protection Sensor is activated at a driving speed of less than 5 km/h. It can detect obstacles within a radius of 5 m—whether it’s a rack column or a pallet stored on the bottom level—and measures the distance to the truck. If the driving speed of the reach truck is too high at the measured distance, the truck’s Rack Protection Sensor slows down the truck automatically.

Proportional braking of the Rack Protection Sensor from Linde Material Handling

Proportional Braking

The Rack Protection Sensor slows down the reach truck in proportion to the distance to the obstacle and the current driving speed. This prevents the truck from coming to an abrupt stop, which could endanger the driver or the load. It is still possible to push pallets using the support arms, however, if the sensor identifies a consistent distance to the pallet, the Rack Protection Sensor does not brake.

Use of polarized light sensors for distance measuring of the Rack Protection Sensor from Linde Material Handling

Perfect Visibility thanks to Polarized Light

The Linde Rack Protection Sensor uses polarized light sensors to measure distances. These sensors impress even in difficult visibility conditions, thanks to their high level of precision. Regardless of the color of the artificial or natural light, the sensor’s red LED point is highly visible and provides the driver with an additional point of orientation for challenging warehouse maneuvers.

Khalil Miri, Warehouse Manager and Safety Officer at RUG SEMIN GmbH, Langen
The reach truck driver needs to store several pallets on the fourth level here, so they look upward and cannot see below. This is where the majority of accidents happen. This is why we need an assistant that automatically brakes the truck.

Khalil Miri, Warehouse Manager and Safety Officer—RUG SEMIN GmbH, Langen

Video on the Rack Protection Sensor from Linde Material Handling

The benefits of the Linde Rack Protection Sensor at a glance

Safety

The Rack Protection Sensor contributes to safer driving at larger lifting heights.

Cost-effectiveness

The Rack Protection Sensor reduces collision damage and saves costs for protection systems on the racks and replacing damaged warehouse systems. It can be retrofitted to older models.

Precision

The special polarized light distance sensors even work with precision in difficult light conditions and are easy to see.

Performance

The Rack Protection Sensor only slows down if the truck’s driving speed is too high at the measured distance. This makes it easier to store and retrieve goods, while the truck is free to move normally at all other times.
